ALLMTN 3
Sold at Dealer Locations Only
$5,800.00
Assembly Options
Professionally assembled by your local dealer, or DIY the assembly - its up to you!
Financing Available
Buy Now, Pay Later with Klarna. We’ve partnered with Klarna to offer flexible payment options to pay over time.
30 Day Returns
Our love your ride guarantee – if you’re not 100% happy with your bike, we’re not happy either. Click here for more details
Frame Warranty
Covered for at least 5 years! Check out the details to see if your bike qualifies for longer.
Brakes
Hydraulic disc
Tire Size
F: 29" / R: 27.5"
Frame material
6061 Aluminum
An all-round e-mountain bike for every terrain: the XDURO AllMtn 3.0! 150mm travel, full suspension, and a powerful Bosch Performance CX motor make for top performance even over challenging terrain. The 650 Wh battery expands your eMTB experience to new levels. Different wheel sizes round off the package: 29" wheels at the front offer precise and comfortable rollover behavior, while the 27.5" wheels at the back give the eMTB perfect traction to master the steepest uphill and downhill slopes.
- Frame Aluminum 6061, thru-axle M12 (1.75) x 148mm, disc brake Post Mount, Travel: 150mm
- Rear Shock RockShox Deluxe RT, air
- Fork RockShox Yari RC Lockout, air, Travel: 160mm, aluminum steerer tube 1 1/8" - 1 1/2" tapered, thru-axle Boost
- Headset A-Head Tapered
- Cranks Haibike forged aluminum
- Sprocket Sram X-SYNC 2, 38 teeth, steel for Bosch direct mount
- Bottom Bracket *
- Front Derailleur *
- Rear Derailleur SRAM SX Eagle, 12-speed
- Shifter SRAM SX Eagle, trigger
- Cogset SRAM PG1210, 11-50 teeth
- Chain SRAM SX Eagle
- Front Hub Shimano MT400, 15mm thru axle, Centerlock disc, 32h
- Rear Hub Shimano MT400, 12mm thru axle, Cassette, Centerlock disc, 32h
- Spokes Stainless Steel, black
- Rims Alex MD30, eyed, double-walled rim, aluminum
- Tires Maxxis Minion DHF, 29" x 2.50" / Maxxis Minion DHR II, 27.5" x 2.80"
- Brake Levers Shimano MT401 Hydraulic
- Pedals MTB Platform pedal aluminum
- Handlebar Haibike Components TheBar ++ 780mm
- Grips Haibike MTB
- Stem Haibike Components TheStem 2, A-head, Bar bore: 31.8mm
- Seat Selle Royale Vivo
- Seatpost XLC, Remote, telescope, 31.6mm
- Detangler *
- Extras *
- Tape *
- Battery Bosch PowerTube 625Wh
- Charger Bosch quick charger 4A
- Motor Bosch Gen4 Performance CX, 250W, 75Nm, 20 mph
- Display Bosch Purion
- Brakes Shimano MT420, Hydraulic disc, 4 Piston, 203mm / 180mm F/R rotors
- Product ID 4700
* Specifications are subject to change without notice
Frame Size | 41 S | 44 M | 47 L | 50 XL |
---|---|---|---|---|
Rider Height | - | - | - | - |
Bike Stand Over Height | 790.0 mm | 800.0 mm | 815.0 mm | 835.0 mm |
Bike Seat Tube Length | 410.0 mm | 440.0 mm | 470.0 mm | 500.0 mm |
Bike Top Tube Length | 567.0 mm | 588.0 mm | 620.0 mm | 654.0 mm |
Bike Head Tube Length | 115.0 mm | 120.0 mm | 130.0 mm | 145.0 mm |
Bike Head Angle | 65.0 ° | 65.0 ° | 65.0 ° | 65.0 ° |
Bike Seat Angle | 76.3 ° | 76.3 ° | 76.3 ° | 76.3 ° |
Bike Wheel Base | 1194.0 mm | 1216.0 mm | 1250.0 mm | 1287.0 mm |
Bike Chain Stay Length | 455.0 mm | 455.0 mm | 455.0 mm | 455.0 mm |
Bike Bb Height | 343.0 mm | 343.0 mm | 343.0 mm | 343.0 mm |
Bike Stem Length | 55.0 mm | 55.0 mm | 55.0 mm | 55.0 mm |
Bike Handlebar Width | 780.0 mm | 780.0 mm | 780.0 mm | 780.0 mm |
Bike Crank Length | 165.0 mm | 165.0 mm | 170.0 mm | 170.0 mm |
Bike Seat Post Length | 295.0 mm | 335.0 mm | 385.0 mm | 385.0 mm |
Bike Stack | 639.0 mm | 643.0 mm | 652.0 mm | 666.0 mm |
Bike Reach | 410.0 mm | 430.0 mm | 460.0 mm | 490.0 mm |
Bike Fork Travel | 160.0 mm | 160.0 mm | 160.0 mm | 160.0 mm |
Bike Fork Length | 575.0 mm | 575.0 mm | 575.0 mm | 575.0 mm |
