FULLSEVEN 5

Coming Fall 2021
$4,650.00
Assembly Options Professionally assembled by your local dealer, or DIY the assembly - its up to you!
Financing Available Buy Now, Pay Later with Klarna. We’ve partnered with Klarna to offer flexible payment options to pay over time.
30 Day Returns Our love your ride guarantee – if you’re not 100% happy with your bike, we’re not happy either. Click here for more details
Frame Warranty Covered for at least 5 years! Check out the details to see if your bike qualifies for longer.
Brakes
4 Piston
Tire Size
27.5"
Frame material
Aluminum

Are you looking for an eBike to tackle steep climbs as well as difficult descents? The FullSeven 5 is your perfect Long Travel-eMTB for every terrain: Its Yamaha PW-ST motor with integrated 500Wh battery gives reliable and powerful support. 150mm rear travel, 4-piston disc brakes and 27.5" wheels with plus tires ensure you have fun while keeping you safe in every situation.

  • Frame Aluminum 6061, thru-axle M12 (1.75) x 148mm, disc brake Post Mount, Travel: 150mm
  • Rear Shock RockShox Deluxe Select Plus Air
  • Fork RockShox FS 35Silver Coil 150mm
  • Headset A-Head, Tapered
  • Cranks Haibike - The Crank + 38t chainring
  • Sprocket Haibike Forged Aluminum, 38 Tooth
  • Bottom Bracket *
  • Rear Derailleur Shimano, Deore M5100
  • Shifter Shimano, Deore M5100, Rapidfire, 11 speed
  • Cogset Shimano, HG5100, 11 - 51 teeth, 11 speed
  • Chain KMC X11e, 11 Speed
  • Front Hub Haibike, TheHub++ Boost, with 15mm thru axle, 32 Hole
  • Rear Hub Haibike The eHub++, Cassette,32 Hole
  • Spokes Black
  • Rims Rodi, Tryp 35, with eyelets, hollow rim, Aluminium
  • Tires Schwalbe, Nobby Nic Evo SnakeSkin, 70-584, 27.5" x 2.80"
  • Brake Levers Tektro HD M745 ORION
  • Pedals Haibike Freeride
  • Handlebar Haibike Components TheBar ++ 740mm
  • Grips Haibike MTB, w/Lock
  • Stem Haibike Components TheStem ++, 60mm, 31.8mm
  • Seat Haibike Components TheSaddle + Mens
  • Seatpost XLC AllMtn, Remote, telescope, 31.6mm
  • Detangler *
  • Tape *
  • Battery Yamaha Lithium Ion 500Wh
  • Charger Yamaha Charger 4 Amp
  • Motor Yamaha PW-ST System, 250W, 70Nm, 20 mph
  • Display Yamaha Side Switch
  • Brakes Tektro, HD M745 Hydrualic, ORION, 4 Piston, 203mm Front, 180mm Rear
  • Product ID 4733

* Specifications are subject to change without notice

Frame Size SM/40 MD/44 LG/48 XL/52
Rider Height - - - -
Bike Stand Over Height 820.0 mm 830.0 mm 850.0 mm 870.0 mm
Bike Seat Tube Length 400.0 mm 440.0 mm 480.0 mm 520.0 mm
Bike Top Tube Length 590.0 mm 600.0 mm 620.0 mm 640.0 mm
Bike Head Tube Length 140.0 mm 125.0 mm 130.0 mm 135.0 mm
Bike Head Angle 67.0 mm 67.0 mm 67.0 mm 67.0 mm
Bike Seat Angle 73.0 mm 73.0 mm 73.0 mm 73.0 mm
Bike Wheel Base 1190.0 mm 1198.0 mm 1219.0 mm 1239.0 mm
Bike Chain Stay Length 470.0 mm 470.0 mm 470.0 mm 470.0 mm
Bike Stack 625.0 mm 612.0 mm 616.0 mm 621.0 mm
Bike Reach 399.0 mm 413.0 mm 432.0 mm 450.0 mm
Bike Fork Travel 160.0 mm 160.0 mm 160.0 mm 150.0 mm
Add Your Review
How Do You Rate This Product?

There are so many factors that determine your eBike’s range: the size of your battery, the level of motor assist you select, and how much weight you are carrying. Going uphill uses more battery than a flat trail.

To help you figure out the most accurate range estimate for your eBike, please try using Bosch’s range finder tool.
