Hydraulic disc
Tire Size
Frame material

Tour or trail? Uphill or downhill? With the HardSeven 5, there is no need for tradeoffs because this is a versatile and agile eMTB. With 120mm travel, Tektro disc brakes, nimble 27.5" wheels and a powerful Bosch Performance Line Cruise motor with a sleek, integrated 500Wh battery you will have a huge amount of fun on and off the trail. Adventures – here we come!

  • Frame Aluminum 6061, thru-axle M12 (1.75) x 142mm, disc brake Post Mount
  • Rear Shock *
  • Fork SR Suntour XCM32 DS Boost 120mm with 15mm thru axle
  • Headset A-Head, Tapered
  • Cranks Haibike Forged Aluminum
  • Sprocket Haibike Forged Aluminum, 38 Tooth
  • Bottom Bracket *
  • Front Derailleur *
  • Rear Derailleur Shimano Alivio SGS, 9 Speed, Shadow type
  • Shifter Shimano Alivio RapidFire Plus, 9 Speed
  • Cogset Shimano HG-200 11-36 Tooth, 9 Speed
  • Chain KMC x9, 9 Speed
  • Front Hub Haibike The Hub +, 32 Hole
  • Rear Hub Haibike The Hub +, 32 Hole
  • Spokes Black
  • Rims Alex MD30 27.5", 21mm
  • Tires WTB Ranger Comp, 27.5x2.25
  • Brake Levers Tektro Hydraulic Levers
  • Pedals XLC Freeride
  • Handlebar XLC Components 720mm
  • Grips XLC MTB, w/Lock
  • Stem XLC Components
  • Seat XLC Components
  • Seatpost XLC Components
  • Detangler *
  • Tape *
  • Battery Bosch Powertube Lithium Ion 500Wh
  • Charger Bosch Compact Charger 2 Amp
  • Motor Bosch Performance Line Cruise, 65 Nm, 20mph
  • Display Purion
  • Brakes Tektro HD-M275, 180mm F&R Rotors
  • Product ID 4734

* Specifications are subject to change without notice

Frame Size SM/40 MD/47 LG/49
Rider Height - - -
Bike Stand Over Height 745.0 mm 733.0 mm 767.0 mm
Bike Seat Tube Length 400.0 mm 470.0 mm 490.0 mm
Bike Top Tube Length 574.0 mm 610.0 mm 640.0 mm
Bike Head Tube Length 125.0 mm 135.0 mm 170.0 mm
Bike Head Angle 65.0 mm 65.0 mm 65.0 mm
Bike Seat Angle 74.8 mm 74.7 mm 74.7 mm
Bike Wheel Base 1217.0 mm 1253.0 mm 1291.0 mm
Bike Chain Stay Length 490.0 mm 490.0 mm 490.0 mm
Bike Bb Drop 54.0 mm 54.0 mm 49.0 mm
Bike Stack 624.0 mm 633.0 mm 660.0 mm
Bike Reach 405.0 mm 437.0 mm 460.0 mm
Bike Fork Travel 110.0 mm 110.0 mm 110.0 mm
Add Your Review
How Do You Rate This Product?

There are so many factors that determine your eBike’s range: the size of your battery, the level of motor assist you select, and how much weight you are carrying. Going uphill uses more battery than a flat trail.

To help you figure out the most accurate range estimate for your eBike, please try using Bosch’s range finder tool.
