Are you looking for an eBike to tackle steep climbs as well as difficult descents? The FullSeven 5 is your perfect Long Travel-eMTB for every terrain: Its Yamaha PW-ST motor with integrated 500Wh battery gives reliable and powerful support. 150mm rear travel, 4-piston disc brakes and 27.5" wheels with plus tires ensure you have fun while keeping you safe in every situation.

  • Bike Frame Aluminum 6061, thru-axle M12 (1.75) x 148mm, disc brake Post Mount, Travel: 150mm
  • Bike Rear Shock RockShox Deluxe Select Plus Air
  • Bike Fork RockShox FS 35Silver Coil 150mm
  • Bike Headset A-Head, Tapered
  • Bike Cranks Haibike - The Crank + 38t chainring
  • Bike Sprocket Haibike Forged Aluminum, 38 Tooth
  • Bike Bottom Bracket *
  • Bike Rear Derailleur Shimano, Deore M5100
  • Bike Shifter Shimano, Deore M5100, Rapidfire, 11 speed
  • Bike Cogset Shimano, HG5100, 11 - 51 teeth, 11 speed
  • Bike Chain KMC X11e, 11 Speed
  • Bike Front Hub Haibike, TheHub++ Boost, with 15mm thru axle, 32 Hole
  • Bike Rear Hub Haibike The eHub++, Cassette,32 Hole
  • Bike Spokes Black
  • Bike Rims Rodi, Tryp 35, with eyelets, hollow rim, Aluminium
  • Bike Tires Schwalbe, Nobby Nic Evo SnakeSkin, 70-584, 27.5" x 2.80"
  • Bike Brake Levers Tektro HD M745 ORION
  • Bike Pedals Haibike Freeride
  • Bike Handlebar Haibike Components TheBar ++ 740mm
  • Bike Grips Haibike MTB, w/Lock
  • Bike Stem Haibike Components TheStem ++, 60mm, 31.8mm
  • Bike Seat Haibike Components TheSaddle + Mens
  • Bike Seatpost XLC AllMtn, Remote, telescope, 31.6mm
  • Bike Detangler *
  • Bike Tape *
  • Bike Battery Yamaha Lithium Ion 500Wh
  • Bike Charger Yamaha Charger 4 Amp
  • Bike Motor Yamaha PW-ST System, 250W, 70Nm, 20 mph
  • Bike Display Yamaha Side Switch
  • Bike Brakes Tektro, HD M745 Hydrualic, ORION, 4 Piston, 203mm Front, 180mm Rear
  • Product ID 4733
Frame Size SM/40 MD/44 LG/48 XL/52
Rider Height - - - -
Bike Stand Over Height 820.0 mm 830.0 mm 850.0 mm 870.0 mm
Bike Seat Tube Length 400.0 mm 440.0 mm 480.0 mm 520.0 mm
Bike Top Tube Length 590.0 mm 600.0 mm 620.0 mm 640.0 mm
Bike Head Tube Length 140.0 mm 125.0 mm 130.0 mm 135.0 mm
Bike Head Angle 67.0 mm 67.0 mm 67.0 mm 67.0 mm
Bike Seat Angle 73.0 mm 73.0 mm 73.0 mm 73.0 mm
Bike Wheel Base 1190.0 mm 1198.0 mm 1219.0 mm 1239.0 mm
Bike Chain Stay Length 470.0 mm 470.0 mm 470.0 mm 470.0 mm
Bike Stack 625.0 mm 612.0 mm 616.0 mm 621.0 mm
Bike Reach 399.0 mm 413.0 mm 432.0 mm 450.0 mm
Bike Fork Travel 160.0 mm 160.0 mm 160.0 mm 150.0 mm
Add Your Review
How Do You Rate This Product?

There are so many factors that determine your eBike’s range: the size of your battery, the level of motor assist you select, and how much weight you are carrying. Going uphill uses more battery than a flat trail.

To help you figure out the most accurate range estimate for your eBike, please try using Bosch’s range finder tool.
